Kaeirda Mig MAG Stick Welding machine MIG-350C

Our Kaeirda Mig Mag Stick welding machine MIG-350C is an IGBT Inverter MIG/MAG/Stick Welding Machine
SKU: RD2010
Call for pricing

Features and Benefits of this welding machine Kaierda Mig MAG Stick Welding machine 350N

Available for welding steel, low carbon steel, and high strength steel; Widely used in Petroleum, chemical, Power Construction, metallurgy, boilers, pressure vessels, pipelines, vehicles, and other manufacturing industry

Complete controllability of welding parameters, accurate preset of current and voltage, convenient to upgrade function
Peak current control mode ensures stable and reliable performance of components
Imported chip IGBT double modules are used in the power device to process full bridge inverter
Waveform technology is adopted to change the welding output waveform, arc shape, spatter amount and weld seam appearance according to the welding requirements
The welding can still be processed when the input voltage is 3phase, 240V-430V due to the excellent function of anti-grid fluctuation
The functions of EMC electromagnetic compatibility and powerful grid filtering reduce the power supply pollution, improve the anti-interference function of the welding machine itself, and protect the inner circuit and components effectively
The welding cable can be lengthened to more than 30m to weld
More stable wire feed speed is realized through microcomputer wire feed control system

Processes for our :

MIG, MAG, MMA, TIG, Carbon Arc Gouging (KE-500N)
Main accessories:
1. Wire feeder: 1set
2. Welding torch: 1PC
3. Regulator: 1PC

SPECIFICATIONS OF KAIERDA WELDERS

Mode

Parameter

MIG-250C

(KE-250N)

MIG-350C

(KE-350N)

MIG-500C

(KE-500N)

Input Voltage

3P~AC380V

Efficiency

50Hz

Rated Input Current(I1max)

17A

26A

36A

Max Effective Current(I1eff)

13A

20A

28A

No load Voltage

55V

70V

70V

Rated output

CO2

40A~250A

45A~350A

50A~500A

MMA

50A~200A

50A~400A

60A~450A

Output Current Range

CO2

40A~280A

45A~350A

50A~500A

MMA

50A~200A

50A~400A

60A~450A

Duty Circle

60%

60%

60%

Protection Class

IP21S

IP21S

IP21S

Insulation Class

H

H

H

COSΦ

≥0.96

≥0.96

≥0.96

Efficiencyη

≥0.88

≥0.88

≥0.88

Weight

15Kg

32Kg

38Kg

Size(mm)

(L×W×H)

468×223×353

634×295×521

634×295×521

Please call and confirm stock availability
